Welcome to RailCon DCC Accessory Control

An innovation in model railway DCC control

Points/Turnout Control

Signal Control

Other Accessories

Take full control of your model railway with RailCon

RailCon is a control system that is:

  • Flexible - mixed slave unit types can be connected to the central control unit
  • Versatile - slave units are available for a wide range of accessory items and the system is compatible with popular computer control software
  • Comprehensive - the central control unit is designed to operate withy any NMRA command system and can be configured for up to 1024 accessory addresses
  • Economical - RailCon provides full DCC control of accessories for a low cost per unit
  • Safe - with features such as optoisolation of the central control unit to protect it and the command station and capacitor timing to protect solenoids
  • Scalable - You can start a DCC accessories control system with just one central control unit and four slave units to control up to eight accessories and expand the system any time by adding more central control units and slave units

RailCon is a Digital Command Control (DCC) based system for controlling model railway accessories, such as:

RailCon is a modular concept that comprises a central control unit to decode DCC accessory control commands and activate slave modules to switch points, signals or other accessories.

The central control unit can connect to four slave modules, each of which can control up to two accessory items, depending on the type of accessory. Slave modules are available for switching points, controlling signals, switching accessories such as street lights and driving turntables.

The central control unit can connect to any combination of slave modules. This provides considerable flexibility in the design of the layout control system. A group of points, signals and other accessories in a particular section of the layout can all be controlled from one central control unit.

The RailCon system has been designed for easy, flexible installation and simple operation using any DCC system that conforms to the National Model Railway Association (NMRA) standard. RailCon is also compatible with popular Personal Computer model railway control software.

The modular design and flexibility of the RailCon system allows the model railway control system to be built in stages.

The RailCon system is made in Australia
